Description
| Material | Stainless Steel (A2) |
| Finish | Natural |
| Manufacturing Standard | DIN 912 |
| Screw Thread Pitch | 1.5mm |
| Thread | M10 (10mm), Right Hand Thread |
| Socket / Allen Key Size (J) | 8mm |
| Head Diameter [Max] (D) | 16mm |
| Head Diameter (D) Tolerance | +0/-0.36mm |
| Head Length [Max] (H) | 10mm |
| Head Length (H) Tolerance | +0/-0.36mm |
| Hexagon Depth (P) | 5mm |
