Description
Material | Stainless Steel (A2) |
Finish | Natural |
Manufacturing Standard | DIN 985 |
For Use With Thread Size | M14 (14mm), Right Hand Thread |
Screw Thread Pitch | 2mm |
Insert Material | Nylon |
Nut Width A/F (J) [Max] | 22mm |
Nut Width A/F Tolerance | +0/0.33mm |
Total Thickness (L) [Max] | 14mm |
Total Thickness (L) Tolerance | +0/-0.7mm |
Hexagon Height (T) [Min] | 9.5mm |
