Description
| Material | Stainless Steel (A2) |
| Finish | CB10 |
| Manufacturing Standard | DIN 7991 |
| Screw Thread Pitch | 0.7mm |
| Thread | M4 (4mm), Right Hand Thread |
| Countersunk Angle (CA) | 90 Degrees |
| Head Length [Max] (H) | 2.48mm |
| Head Diameter [Max] (D) | 8.96mm |
| Head Diameter [Min] (D) | 7.53mm |
| Hexagon Across Flats / Allen Key Size (J) |
2.5mm |
| Hexagon Depth (P) |
1.5mm |
For larger quantities or sizes not listed, please email frank@franksfasteners.co.uk and we will be happy to provide you with a quotation.
