Description
Material | Steel |
Finish | Zinc Plated |
Manufacturing Standard | DIN 985 |
For Use With Thread Size | M5 (5mm), Right Hand Thread |
Screw Thread Pitch | 0.8mm |
Insert Material | Nylon |
Nut Width A/F (J) [Max] | 8mm |
Nut Width A/F Tolerance | +0/0.22mm |
Total Thickness (L) [Max] | 5mm |
Total Thickness (L) Tolerance | +0/-0.3mm |
Hexagon Height (T) [Min] | 3.2mm |
